Q 1 :

In the given circuit, the terminal potential difference of the cell is              [2024]

  • 4 V



  • 2 V



  • 3 V



  • 1.5 V



(2)

Current supplied by battery, i=31+2=1A

The terminal potential difference of the cell

V=E-ir=3-1×1=2V





Q 2 :

A potential divider circuit is shown in figure. The output voltage V0 is                     [2024]

  • 4 V



  • 2 mV



  • 0.5 V



  • 12 mV



(3)

Req=4000Ω

i=44000=11000A

V0=(i)(500Ω)

       =11000×500=0.5 volt





Q 3 :

The reading in the ideal voltmeter (V) shown in the given circuit diagram is             [2024]

  • 5 V



  • 10 V



  • 0 V



  • 3 V



(3)

i=Eeqreq=8×58×0.2

I=25A

Reading of Voltmeter V=E-ir=5-0.2×25=0



Q 4 :

A galvanometer (G) of 2Ω resistance is connected in the given circuit. The ratio of charge stored in C1 and C2 is         [2024]

  • 23



  • 32



  • 1



  • 12



(4)

Resistance R=12Ω

Current i=612=12A

q4μFq6μF=4×10-6×36×10-6×4=12



Q 5 :

The current flowing through the 1Ω resistor is n10A. The value of n is ______ .                    [2024]



(25)

At junction y,

y-52+y-02+y-(x-10)1=0

y-5+x+3x-40-4y=0

4y-2x+15=0                                       ...(i)

At junction x, x-54+x-04+(x-10)-y1=0

x-5+x+4x-40+4y=0

6x-4y-45=0                                    ...(ii)

x=152V and y=0

i1=y-(x-10)1=0-7.5+101

i1=2.5A=n10An=25



Q 6 :

Two cells are connected in opposition as shown. Cell E1 is of 8 V emf and 2Ω internal resistance; the cell E2 is of 2 V emf and 4Ω internal resistance. The terminal potential difference of cell E2 is ____ V.            [2024]



(6)

req=r1+r2=(2+4)Ω=6Ω

Current in the loop, i=εeqreq=6V6Ω=1A

Terminal potential difference of cell E2E2+ir2

[2+(1)(4)]V6V
